铣削电机功率: Milling motor power

 P= 5.5Kw;1440rpm

 机床外形尺寸: Overall dimensions of machine

 长x宽x高(length x width x height) = 4150 x 1475 x 3040mm

 滑台尺寸: Dimensions of slide table

 长x宽(length x width) = 1200 x 900mm

 滑台最大行程: Maximum stroke of slide table

 L= 1400mm

 滑台工进移动速度: Processing speed of slide table

 V = 50~440mm/min

 滑台快退速度: Quick moving speed of slide table

 V = 660mm/min

 水平进给电机功率: Power of traverse feed motor

 P=4kw;1440pm

 垂直进约电机功率: Longitudinally feeding motor power

 P= 1.5Kw;1440rpm

 切削刀盘直径: Diameter of cutter head

 D= 125 ~ 250mm

 铣削头主轴转速: Rotary speed of spindle of milling unit

 n= 125 - 630rpm

 铣削头主轴伸出移动量:Protruding movement of spindle of milling unit

 L = 70mm

 垂直进给速度: Longitudinally feeding speed

 v= 55 ~ 500mm/min

 铣头快速升降速度: Quick lift speed of milling unit

 500mm
